21.2.6 Trade Counter
The indicator does not check to see if new data is different from the old data before incrementing the trade
counter, so sending IAD1,6000 will increment the counter even if the indicator is set up with a fullscale of 6000
kg already. Query the trade counter with command TDD? (see Section 21.3.51).
21.3 Extended Command Set: Details
21.3.1 ACL: Auto Calibration
This command no longer performs any function, but is still available for backward compatibility. The C500
series hardware does not need to perform an auto-calibration routine.
Important:
ACL only valid in INDUSTRIAL mode
Power loss resets the indicator i.e. ACL1,1 is valid
Without auto-calibration the accuracy of the instrument will drop over longer periods
General
No. of parameters 2
Save changes Not possible
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Auto-calibration at standstill 0 = Off
1 = On
1
2 Auto-calibration at motion 0 = Off
1 = On
1
21.3.2 ADR: Network Address
Set the address of a unit.
General
No. of parameters 2
Save changes With TDD1
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Address 0 .. 31 31
2 Serial Number “0000001” .. “9999999” “xxxxxxx” factory set
Each indicator must be assigned a unique address to enable the implementation of a multi-drop network. This
address can be set using the digital setup menus as described in the reference manual. It is also possible to use
the network itself to set the unit addresses. The address command is used to assign the unit address via the
communications network.
Example 1: Change address of unit from 1 to 2
Command Answer Description
S01; Select unit 1
ADR2; 0 CRLF Set address to 2
TDD1; 0 CRLF Save change
S02; Select new unit 2
IDN?; "C520","0123456","1.0.4","C520"CRLF Ask for ID
121 C500-600-2.0.3
