20.3 Object Model
Ethernet/IP represents data as objects. The objects supported by the C500 are described here.
20.3.1 Identity Object (Class 01
H
)
The following table describes the attribute, status, and common services information for the Identity Object.
Instance Attribute ID Name Object Value Access
0 (Class) 1 Revision UINT 1 Get
1 1 Vendor ID UINT 1501 Get
1 2 Device type UINT 43 Get
1 3 Product code UINT 1 Get
1 4 Product revision
Bytes Type Description Value
0 USINT Major revision 2
1 USINT Minor revision 64
Get
1 5 Status UINT See Section 20.3.2 Get
1 6 Serial number UDINT C500 serial number Get
1 7 Product name STRING Rinstrum C500 Get
1 8 State USINT See Section 20.3.2 Get
The services provided by the identity object are as follows:
Service Code Service Name Class Level Instance Level
0E
H
GAS Yes Yes
01
H
GAA No Yes
10
H
SAS No No
05
H
Reset No Yes
20.3.2 Identity Object State and Status
The following table maps the indicator errors into EIP faults. The columns are as follows:
 Indicator Error are the error codes listed in Section 24.4
 EIP EDS is the Extended Device Status bits (4-7) within the identity object status UDINT (attribute 5)
 EIP Fault bit are the fault bits (8,9,10,11) within the identity object status UDINT (attribute 5)
 EIP State is the identity object state USINT (attribute 8)
 See ODVA Vol 1: Identity object for more information
Indicator Error EIP EDS EIP Fault Bit EIP State
E00000 0 None Operational (3)
E00001 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00002 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00004 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00008 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00010 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00020 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
E00080 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00100 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
E00200 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E00400 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
103 C500-600-2.0.3
