8 Automatic Weight Output
8.1 Introduction
The automatic output is normally used to drive remote displays, dedicated computer connections or PLCs.
The output generates a simple weight message at predefined intervals.
8.2 Formats
There are 6 automatic output formats, including one custom format. The start and end characters of the
format strings can be set (even for the standard formats) in the SERIAL:AUT.OPT menu.
Basic format:
Start Format End1 End2
where:
Start: Start character (set in SERIAL:AUT.OPT:ST.CHR)
Format: Format string (set in SERIAL:AUT.OPT:TYPE)
End1: 1st termination character (set in SERIAL:AUT.OPT:END.CH1)
End2: 2nd termination character (set in SERIAL:AUT.OPT:END.CH2)
8.2.1 Format A
Format:
Sign Weight Status
where:
Sign (1 character): SPACE or ‘-’
Weight (7 characters): The weight in 7 characters with decimal point and leading spaces.
Status (1 character) = ‘G’, ‘N’, ‘U’, ‘O’, ‘M’ or ‘E’ for Gross, Net, Underload, Overload, Motion and
Error.
8.2.2 Format B
Format:
Status Sign Weight Units
where:
Status (1 character) = ‘G’, ‘N’, ‘U’, ‘O’, ‘M’ or ‘E’ for Gross, Net, Underload, Overload, Motion and
Error.
Sign (1 character): SPACE or ‘-’
Weight (7 characters): The weight in 7 characters with decimal point and leading spaces.
Units (3 characters): Weight units with leading spaces, e.g. kg’ or t’. When the weight is unstable
is sent.
8.2.3 Format C
Format:
Sign Weight S1 S2 S3 S4 Units
47 C500-600-2.0.3
