6 Operator Menus
The operator menus provide access to some settings typically used by operators. These do not require access
to safe or full setup.
Items Name Description
Setpoint Targets TARGET The target menu displays the sepoint targets for
active setpoints only. Inactive and other setpoint
types are hidden.
Setpoint 1 Target TARG1
Setpoint 2 Target TARG2
Setpoint 3 Target TARG3
Setpoint 4 Target TARG4
Setpoint 5 Target TARG5
Setpoint 6 Target TARG6
Setpoint 7 Target TARG7
Setpoint 8 Target TARG8
Setpoint Inflights FLIGHT The inflight menu displays the sepoint inflight
values for active setpoints only. Inactive and
other setpoint types are hidden.
Setpoint 1 Inflight FLT 1
Setpoint 2 Inflight FLT 2
Setpoint 3 Inflight FLT 3
Setpoint 4 Inflight FLT 4
Setpoint 5 Inflight FLT 5
Setpoint 6 Inflight FLT 6
Setpoint 7 Inflight FLT 7
Setpoint 8 Inflight FLT 8
USB USB The USB menu allows you to quickly eject a USB
disk. This menu is only available when a USB
disk is mounted.
Eject USB disk EJECT Eject the USB disk.
User numbers and strings USER The user menu allows you to edit the user strings
and numbers. These only appear if the corre-
sponding name register has been set.
User number 1 <Value of register 0x0316> Edit user number 1 (register 0x0310)
User number 2 <Value of register 0x0317> Edit user number 2 (register 0x0311)
User number 3 <Value of register 0x0318> Edit user number 3 (register 0x0312)
User number 4 <Value of register 0x0319> Edit user number 4 (register 0x0313)
User number 5 <Value of register 0x031A> Edit user number 5 (register 0x0314)
User string 1 <Value of register 0x0080> Edit user string 1 (register 0x0090)
User string 2 <Value of register 0x0081> Edit user string 2 (register 0x0091)
User string 3 <Value of register 0x0082> Edit user string 3 (register 0x0092)
User string 4 <Value of register 0x0083> Edit user string 4 (register 0x0093)
User string 5 <Value of register 0x0084> Edit user string 5 (register 0x0094)
Current IP Settings IP.INFO This menu allows you to quickly view the IP set-
tings of the indicator. These settings can only
be changed from the Ethernet setup menu. See
Section 5.6.
DHCP enable DHCP View whether IP setup is obtained via DHCP.
IP address IP View the currenly assigned IP address.
39 C500-600-2.0.3
