To enter the ASCII value, use the left and right keys to change the selected digit and the up and down
keys to change that digit
Use the OK key to advance to the next character in the string
Press the cancel key to exit the editor (changes will be saved)
5.1.9 Editing With Functions
Some settings have a special function to control their use. These are not simple settings but are more complex
routines. Examples are CAL:ZERO or TEST:SCALE. To use:
Press the OK key to start the function
All functions are different and there are no standard keys. The user will be prompted for what is required.
Use the cancel key to exit the function
5.1.10 Exit
There are several methods of exiting the setup menu.
Method 1: Save and exit
– Long press the OK key.
Method 2: Save and exit
1. Press the Zero key until -END- is shown.
2. Press the OK key
Method 3: Save and exit
– Press the rear key
Method 4: Exit without saving
– Remove the power from the instrument.
5.2 BUILD: Scale Build Menu
Items in this group configure the scale build. It is important to set the build options before calibrating.
Changes after calibration may invalidate the calibration.
Items Name Description
Scale type ⊕ TYPE Selects the number of ranges used. Options are:
SINGLE(def): Single range
DUAL I: Dual interval
DUAL R: Dual range
Decimal point position ⊕ DP Sets the decimal point position on the display. Options are:
000000(def)
00000.0
0000.00
000.000
00.0000
0.00000
Range 1 scale capacity ⊕ CAP1 Sets the maximum capacity of the scale. If BUILD:TYPE=DUAL I
or BUILD:TYPE=DUAL R, it sets the capacity of the 1st range.
Default: 3000.
18 C500-600-2.0.3
