Rinstrum C530 User Manual

E00800 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E01000 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E02000 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E04000 5 (major fault) Major Recoverable (bit 10) Major Recoverable Fault (4)
E08000 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
E10000 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
E20000 5 (major fault) Major Unrecoverable (bit 11) Major Unrecoverable Fault (5)
20.3.3 Assembly Object (Class 04
H
)
Instance Attribute ID Name Object Access
0 (Class) 1 Revision UINT (value 2) Get
0 (Class) 2 Max instance UINT (value 129) Get
100 3 T->O Primary
Units Simple
Weight
Bytes Type Description
0-3 DINT Displayed Weight
4 SINT Units
5 SINT Decimal Point
6-7 INT Weight Status (16bit)
See Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
Get
101 3 T->O Primary
Units Full Weight
Bytes Type Description
0-3 DINT Displayed Weight
4-7 DINT Gross Weight
8-11 DINT Net Weight
12-15 DINT Tare Weight
16 SINT Units
17 SINT Decimal Point
18-19 INT Weight Status (16bit)
20-23 DINT Extended Status (32bit)
24-27 DINT I/O Status (32bit)
See
Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
See Section 20.3.3 for extended status bits
See Section 20.3.3 for I/O status bits
Get
102 3 T->O Secondary
Units Simple
Weight
Bytes Type Description
0-3 DINT Displayed Weight
4 SINT Units
5 SINT Decimal Point
6-7 INT Weight Status (16bit)
See
Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
Get
104 C500-600-2.0.3
