Rinstrum C530 - Page 110

103 3 T->O Secondary
Units Full Weight
Bytes Type Description
0-3 DINT Displayed Weight
4-7 DINT Gross Weight
8-11 DINT Net Weight
12-15 DINT Tare Weight
16 SINT Units
17 SINT Decimal Point
18-19 INT Weight Status (16bit)
20-23 DINT Extended Status (32bit)
24-27 DINT I/O Status (32bit)
See
Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
See Section 20.3.3 for extended status bits
See Section 20.3.3 for I/O status bits
Get
104 3 T->O Tertiary
Units Simple
Weight
Bytes Type Description
0-3 DINT Displayed Weight
4 SINT Units
5 SINT Decimal Point
6-7 INT Weight Status (16bit)
See
Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
Get
105 3 T->O Tertiary
Units Full Weight
Bytes Type Description
0-3 DINT Displayed Weight
4-7 DINT Gross Weight
8-11 DINT Net Weight
12-15 DINT Tare Weight
16 SINT Units
17 SINT Decimal Point
18-19 INT Weight Status (16bit)
20-23 DINT Extended Status (32bit)
24-27 DINT I/O Status (32bit)
See
Section 21.3.17 for units values
See Section 21.3.22 for decimal point values
See Section 20.3.3 for weight status bits
See Section 20.3.3 for extended status bits
See Section 20.3.3 for I/O status bits
Get
105 C500-600-2.0.3
