Rinstrum C530 User Manual

106 3 T->O System
Status
Bytes Type Description
0-3 DINT Extended Status (32bit)
4-7 DINT System Error (32bit)
8-11 DINT I/O Status (32bit)
12-15 DINT I/O Mask (32bit)
16 SINT Primary Units
17 SINT Primary Decimal Point
18 SINT Primary Range 1 Resolution
19 SINT Primary Range 2 Resolution
20 SINT Primary Range 3 Resolution
21 SINT Unused (always 0)
22 SINT Unused (always 0)
23 SINT Unused (always 0)
24 SINT Secondary Units
25 SINT Secondary Decimal Point
26 SINT Secondary Range 1 Resolution
27 SINT Secondary Range 2 Resolution
28 SINT Secondary Range 3 Resolution
29 SINT Unused (always 0)
30 SINT Unused (always 0)
31 SINT Unused (always 0)
32 SINT Tertiary Units
33 SINT Tertiary Decimal Point
34 SINT Tertiary Range 1 Resolution
35 SINT Tertiary Range 2 Resolution
36 SINT Tertiary Range 3 Resolution
37 SINT Unused (always 0)
38 SINT Unused (always 0)
39 SINT Unused (always 0)
See Section 21.3.17 for units values
See Section 21.3.22 for decimal point and range
resolution values
See Section 20.3.3 for extended status bits
See Section 20.3.3 for I/O status bits
See Section 24.4 for system errors
