Name Address Type R W Description
System status 0021
H
uint32 A N Read current system status. Bits are as
follows:
0-7: Last calibration result
8: Reserved
9: Scale is in Net mode
10: Scale is within the zero band
11: Scale is within center of zero
12: Scale is in motion
13: Calibration is in progress
14: Menus are active
15: Scale is in error
16: Scale is underloaded
17: Scale is overloaded
18: ADC operation has succeeded
19: ADC operation in progress
20: Tilt Hi XY (not supported in C500)
21: Tilt Hi Y (not supported in C500)
22: Tilt Hi X (not supported in C500)
System error 0022
H
uint32 A N Read current system error. Refer to
Section 24.4 for values.
Absolute mV/V 0023
H
int32 A N Absolute mV/V reading where 10000 =
1.0mV/V
Gross/Net Weight 0025
H
weight A N Displayed weight in primary units
Gross Weight 0026
H
weight A N Gross weight in primary units
Net Weight 0027
H
weight A N Net weight in primary units
Tare Weight 0028
H
weight A N Tare weight in primary units
Peak Hold 0029
H
weight A N Peak hold weight in primary units
Secondary Gross Weight 002C
H
weight A N Gross weight in secondary units
Raw ADC Counts 002D
H
int32 A N 2,560,000 = 1.0mV/V
Secondary Net Weight 002E
H
weight A N Net weight in secondary units
System Fullscale 002F
H
uint32 A N Full scale capacity
Traceable weight available
flag
0030
H
uint8 A N 0: No traceable weights since start up.
1: Traceable weight data is valid
Traceable ID 0031
H
uint32 A N The unique ID for the traceable weight
Traceable weight 0032
H
weight A N Traceable weight in primary units
Traceable weight (secondary) 0033
H
weight A N Traceable weight in secondary units
Traceable weight (p) 0034
H
int32 A N Traceble weight in pieces
Traceable tare weight 0035
H
int32 A N Tare weight valid during traceable weight
Traceable PT Flag 0036
H
uint8 A N 0: no preset tare
1: preset tare
Traceable date: year 0037
H
uint8 A N Year that the traceable weight was
acquired
Traceable date: month 0038
H
uint8 A N Month that the traceable weight was
acquired
Traceable date: date 0039
H
uint8 A N Day that the traceable weight was
acquired
Traceable date: hour 003A
H
uint8 A N Hour that the traceable weight was
acquired
Traceable date: minute 003B
H
uint8 A N Minute that the traceable weight was
acquired
79 C500-600-2.0.3
