Rion VA-12 User Manual

96
Trigger Functions
Frequency
span(Hz)
Number
of lines
Frame
time(s)
Overlap
ratio *
Max. averaging
1 min.
(60 sec)
5 min.
(300 sec)
10 min.
(600 sec)
30 min.
(1800 sec)
60 min.
(3600 sec)
1000 200 0.2 0.5 579 2048 2048 2048 2048
1000 400 0.4 0.5 289 1489 2048 2048 2048
10008000.80.5 144 744149420482048
1000 1600 1.6 0.5 71 371 746 2048 2048
1000 3200 3.2 0.5 35 185 372 1122 2048
2000 200 0.1 0 580 2048 2048 2048 2048
2000 400 0.2 0 290 1490 2048 2048 2048
20008000.4 0 145 745149520482048
2000 1600 0.8 0 72 372 747 2048 2048
2000 3200 1.6 0 36 186 373 1123 2048
5000 200 0.04 0 1450 2048 2048 2048 2048
5000 400 0.08 0 725 2048 2048 2048 2048
5000 800 0.16 0 362 1862 2048 2048 2048
5000 1600 0.32 0 181 931 1868 2048 2048
5000 3200 0.64 0 90 465 934 2048 2048
10000 200 0.02 0 2048 2048 2048 2048 2048
10000 400 0.04 0 1450 2048 2048 2048 2048
10000 800 0.08 0 725 2048 2048 2048 2048
10000 1600 0.16 0 362 1862 2048 2048 2048
10000 3200 0.32 0 181 931 1868 2048 2048
20000 200 0.01 0 2048 2048 2048 2048 2048
20000 400 0.02 0 2048 2048 2048 2048 2048
20000 800 0.04 0 1450 2048 2048 2048 2048
20000 1600 0.08 0 725 2048 2048 2048 2048
20000 3200 0.16 0 362 1862 2048 2048 2048
*
Even if the overlap ratio is 0, there will be no dropping of waveform samples during processing
(except when repeat trigger is used).
