Rion VA-12 User Manual

130
Data File Structure
Item Header string Bytes Content Bytes Description
Number of analysis
line
Analysis
Line 13
200, 400, 800,
1600, 3200
3 to 4
Average display Average
Disp 12 Lp, Ave 2 to 3
Operation type Average
Type 12 Linear, Exp, Max 6
Average number Average
Count 13 1 to 2048 1 to 4
Current completed
averaging count
Average
Complete 16 1 to 9999 1 to 4
Time window
function
Window
Function 15
Rectangular,
Hanning, Flattop
7 to 11
Accelerometer
sensitivity (numeral)
Actual
Sensitivity
Num
22 100 to 999 3
Accelerometer
sensitivity (factor)
Actual
Sensitivity
Magnify
26
×0.1, ×0.01,
×0.001
4 to 6
Sensor selection Sensor
Type 11 PV-57I, Other 5 to 6
Measurement start
time
Start
Time 10
YYYY/MM/DD
hh:mm:ss
19
Trigger mode Trigger
Mode 12
Free, Repeat,
Single, Time
4 to 6
Trigger source Trigger
Source 14
Level Trigger,
External Trigger
13 to 16
Trigger level Trigger
Level 13 −7 to +7 2
Trigger slope Trigger
Slope 13 −, + 1
Pretrigger Pretrigger 10 OFF, ON 4 to 10
Store name Store
Name 10 0 to 9999 1 to 4
Store address Store
Address 13 1 to 1000 1 to 4
Store number Store
Number 12 1 to 1000 1 to 4
Store interval Store Interval 14
1 min, 5 min,
10 min, 30 min,
60 min
4 to 5
Timer store start
time
Store
Start Time 16
YYYY/MM/DD
hh:mm:ss
19
