Menu Operation
Menu structure
The menus of the VA-12 are organized in a hierarchical structure. To return
to the next higher level from a lower level, press the MENU key.
Bold: Screen name, Regular font: Item name
*: Can also be selected in recall mode
Higher Lower Available settings
Menu List
System (Language)
Backlight Brightness ...... Dark / Bright
Backlight Auto-Off ...... 30s / 3min / Cont.
Read/Save Setting
Setting
SYSTEM/Setting
SD read
Time Setting
Current Time
Beep ...... OFF / ON
System-Program Information
Program Information
Language ......
/ English
SD Card Format ...... Off / Exec / Full
Measurement *
Store Name ...... MAN_0000 to MAN_9999
Trigger Mode ...... Free / Repeat / Single / Time
Wave Record ...... OFF / ON
Trigger source ...... Level / External
Pre-Trigger ...... OFF / ON
Trigger Level ...... −7/8 to 7/8
Slope ...... − / +
Trigger Start Time ...... 00:00 to 23:59
Store Interval ...... 1min / 5min / 10min / 30min / 60min
Store number ...... 0001 to 1000
Display *
VM Scale * ...... Log / Linear
FFT Scale * ...... Log / Linear
X unit * ...... Hz / kcpm / odr
Standard Frequency ...... 0.03125 Hz to 20.00000 kHz
Y unit * ...... Log / Linear
Level List ...... Off / On
Time Level ...... Off / On
Overlapping ...... Off / On / Clear
Analog Input *
High-pass Filter ...... 1 Hz / 3 Hz / 10 Hz / 1 kHz
Low-pass Filter ...... 1 kHz / 5 kHz / 20 kHz
Sensor Selection ...... PV-57I / Other
Sensitivity ...... PV-57I: 100 × 0.01 mV/ms
−2
to 999 × 0.01 mV/ms
−2
Other: 100 × 0.001 mV/ms
−2
to 999 × 0.1 mV/ms
−2
FFT *
Window Func. ...... Rectangular / Hanning / Flat top
Operation Type ...... LIN / EXP / MAX
Average number ...... 0001 to 2048
Print *
Save to SD*
Print *
Cancel *
Recall
