40
Measurement in Vibration Meter Mode
Storing measurement data
You can store measurement data on an SD card inserted in the unit.
When using the time trigger function to store data, refer to the “Trigger
Functions” section.
1. Verify that the SD card symbol
is shown on the title bar.
If no symbol is shown, insert an SD card.
2. Check the store address shown at the right end of the title bar.
• If the address is shown on a white background:
Proceed to step 3.
• If the address is shown on a red background:
This indicates that the store address already contains measurement
data. If the data can be overwritten, proceed to step 3.
If you do not want to overwrite the data, use the
/ keys to
select a different store address that is shown on a white background.
3. Press the STORE key.
The popup indication “STORE XXXX” (where XXXX is the store
address) appears, storing is carried out, and the LED indicator ashes
in red.
When storing is complete, the store address is incremented by one.
If the store address was 1000, the indication returns to 0001.
For information on how to view stored data, refer to the “Recalling Stored
Data” section. For information on the folder structure of stored data, refer
to the “SD Card” section.
