Rion VA-12 User Manual

37
Measurement in Vibration Meter Mode
Changing measurement parameters and display
parameters
The measurement parameters and display parameters in vibration meter
mode are as follows.
Menu Key operation
See
page
Measurement parameter
Sensor information Analog Input - 15, 38
High-pass  lter Analog Input
- 33
Low-pass  lter Analog Input
- 33
Input range
- RANGE / 38
Trigger operation settings Measure
- 95
Store name Measure
- 38
Measurement data type
(data shown as bar graph)
- ACC/VEL/DISP 32
Display
parameter
Vibration meter scale Display
-
38
For information on menu structure and menu operation, see the “Menu
Operation” section.
Restriction for changing measurement parameters
In the following cases, measurement parameters
cannot be changed.
• During measurement pause (
symbol shown on
left side of display)
• During time trigger operation
