38
Measurement in Vibration Meter Mode
Making sensor settings
Use the supplied calibration chart of the accelerometer you intend to use, and
make the sensitivity setting by performing the following steps.
1. From the [Analog Input] menu screen, select [Sensor Selection] and
then [PV-57I] or [Other].
2. Set [Sensitivity] to the sensitivity value given on the calibration
chart.
Note
When selecting [PV-57I], a popup window appears,
asking whether you want to change the sensitivity
setting. Also note that the factor cannot be changed.
Changing the input range
Set the input range to an optimum setting.
If overload occurs (measurement value display background is red, and
Over
indication appears on right side of display), the input range setting
is too low. Use the RANGE key to increase the setting.
Specifying the store name
To store measurement data, it is necessary to rst specify a store name.
Access the [Measure] menu and select [Store Name].
Measurement data will be stored in a folder of the speci ed name. (See
the “SD Card” section.)
Selecting the vibration meter scale
1. From the [Display] menu screen, select [VM Scale].
2. Select one of the following.
Log: Logarithmic scale
Linear: Linear scale
To Next Page
