Rion VA-12 User Manual

65
Measurement in FFT Mode
Changing measurement parameters and display parameters
The measurement parameters and display parameters in FFT mode are as
follows.
Menu Key operation
See
page
Measurement parameter
Sensor information Analog Input - 15, 65
High-pass  lter Analog Input
- 56
Low-pass  lter Analog Input
- 56
Measurement data type
- ACC/VEL/DISP 58
Input range
- RANGE / 56
Frequency span Measure FREQ SPAN 57
Number of analysis lines Measure LINE 57
Trigger operation settings Measure - 93 to 96
Window function FFT
- 57
Operation type FFT
- 67
Average number FFT
- 67
Store name Measure
- 67
Waveform data recording
function
Measure
- 77
Display
parameter
FFT scale Display - 68
Cursor X axis unit Display
- 68
Cursor Y axis unit Display
- 62
Overlay display Display
- 110
For information on menu structure and menu operation, see the “Menu
Operation” section.
Making sensor settings
Use the supplied calibration chart of the accelerometer you intend to use, and
make the sensitivity setting by performing the following steps.
1. From the [Analog Input] menu screen, select [Sensor Selection] and
then [PV-57I] or [Other].
2. Set [Sensitivity] to the sensitivity value given on the calibration
chart.
Note
When selecting [PV-57I], a popup window appears,
asking whether you want to change the sensitivity
setting. Also note that the factor cannot be changed.
