Measurement in Vibration Meter Mode
Performing measurement
The measurement will start automatically when the vibration meter mode
measurement screen is brought up. The following values are measured
simultaneously and updated in 1-second intervals.
• Acceleration rms value (m/s
2
)
• Acceleration peak value (m/s
2
)
• Acceleration crest factor
• Velocity rms value (mm/s)
• Displacement equivalent p-p value (mm)
For information on how to use the time trigger function to save data, see the
“Trigger Functions” section.
Pausing the measurement
To pause the measurement, press the PAUSE/CONT key.
During pause, the symbol is shown on the left side of the display.
To resume the measurement, press the PAUSE/CONT key once more.
Note
In the pause condition (
symbol shown on left side
of display), the measurement parameters cannot be
changed.
