Setup Files and Initialization
Setting item Setting command Default value
Display (menu setting)
*
Vibration meter graph X axis
scale
Scale VM Linear
* FFT graph Y axis scale Scale Unit FFT Y Linear
* FFT cursor X axis unit Cursor Unit FFT X Hz
* FFT cursor Y axis unit Cursor Unit FFT Y Linear
* Level list display List Display Off
* Time display Time Display On
* Overlay display Layer Display Off
Analog Input
*High-pass  lter High Pass Filter 3 Hz
*Low-pass  lter Low Pass Filter 5 kHz
* Sensor selection Sensor Type PV-57I
*
Accelerometer sensitivity
(numeral)
Pickup Sensitivity Num 510
*
Accelerometer sensitivity
(factor)
Pickup Sensitivity Magnify 0.1
FFT
* Time window function Window Function Hanning
* Averaging display Average Disp Instantaneous value
* Operation type Average Type Linear
Display (key setting)
* FFT X axis zoom FFT Expand X ×1
* FFT Y axis zoom (Log) FFT Expand Y Log 80
* FFT Y axis zoom (Lin) FFT Expand Y LIN 0
*
Time waveform X axis
zoom
TIME Expand X ×1
*
Time waveform Y axis
zoom
TIME Expand Y 0
*
X axis upper limit (line
position)
X Upper 200
*
X axis lower limit (line
position)
X Lower 0
*
FFT cursor position (line
position)
Cursor Position FFT 0
* FFT (list) cursor position Cursor Position LIST 0
*
Time waveform cursor posi-
tion
Cursor Position Time 0
* Zoom on/off Zoom Mode Off
* Zoom/Move mode Zoom Move Zoom mode
Store address Store Address 0001
