76
Measurement in FFT Mode
2. Check the store address shown at the right end of the title bar.
• If the address is shown on a white background:
Proceed to step 3.
• If the address is shown on a red background:
This indicates that the store address already contains measurement
data. If the data can be overwritten, proceed to step 3.
If you do not want to overwrite the data, use the
/ keys to
select a different store address that is shown on a white background.
Note
If the graph zoom symbol
is shown at the bottom
left of graph, press the SCALE EXPAND/MOVE key
or the SCALE ON/OFF key. Verify that the symbol
is now
or that no symbol is shown, and then use
the
/ keys.
3. Press the STORE key.
4. The popup indication “STORE XXXX” (where XXXX is the store
address) appears, storing is carried out, and the LED indicator ashes
in red.
When storing is complete, the store address is incremented by one.
If the store address was 1000, the indication returns to 0001.
For information on how to view stored data, refer to the “Recalling Stored
Data” section. For information on the folder structure of stored data, refer to
the “SD Card” section.
