3.5. PNEUMATIC DEVICE DESCRIPTION (PACK 5040A-6050A)
T
he
p
icture shows the
p
osition of the devices.
A) Pneumatic c
y
linder: allows the movement of the weldin
g
arm.
B) YV1 Solenoid valve: activates the movement of the
p
neumatic c
y
linder.
C)
T
a
p
: to eliminate the
p
neumatic
p
ressure inside the machine.
D) Reducing valve with filter and manometer: this is needed to regulate the system’s general pressure.
T
urn knob to chan
g
e the
p
ressure values indicated on the
p
ressure
g
au
g
e.
E) YV0 Solenoid valve: To eliminate the pneumatic pressure inside the machine in case of an emergency
Sto
p
.
|
Important
For further details see the
p
neumatic dia
g
ram.
3.6. TECHNICAL SPECIFICATIONS
The table below shows the technical specifications of the machine.
Description Units
of
measur‑
ement
PACK
5040M
PACK
6050M
PACK
5040A
PACK
6050A
Supply voltage V 400
3Ph+N
400
3Ph+N
400
3Ph+N
400
3Ph+N
Mains frequency Hz 50-60 50-60 50-60 50-60
Installed power kW 5,7 7,4 5,7 7,4
Max hourly production time (∗) packag‑
es/hour
600 600 900 900
