Robustel GoRugged R3000 Lite User Manual

Robustel GoRugged R3000 Lite User Guide
RT_UG_R3000 Lite_v.1.4.1 15.11.2016 13 / 135
Confidential
1.3 Specifications
Cellular Interface
 Standards: GSM/GPRS/EDGE/UMTS/TD-SCDMA/EVDO/HSPA+/LTE
 GSM: max. 9.6/2.7 Kbps (DL/UL)
 GPRS: max. 86 Kbps (DL & UL), class 10
 EDGE: max. 236.8 Kbps (DL & UL), class 12
 UMTS: max. 384 Kbps (DL & UL)
 TD-SCDMA: max. 2.8 Mbps/384 Kbps (DL/UL)
 EVDO: max. 14.7/5.4 Mbps (DL/UL)
 HSPA+: max. 21.6/5.76 Mbps (DL/UL)
 FDD LTE: max. 100/50 Mbps (DL/UL)
 TDD LTE: max. 100/50 Mbps (DL/UL)
 SIM: 2 x (3 V & 1.8 V)
 Antenna interface: SMA female
Cellular interface
The number of antenna interface
3G HSDPA
1
3G HSPA+
2
4G LTE
2
Ethernet Interface
 Number of ports: 1 x 10/100 Mbps
 Magnet isolation protection: 1.5 KV
Serial Interface
 Number of ports: 1 x RS232 and 1 x RS485
 ESD protection: ±15 KV
 Parameters: 8E1, 8O1, 8N1, 8N2, 7E2, 7O2, 7N2, 7E1
 Baud rate: 300 bps to 230400 bps
 RS232: TxD, RxD, RTS, CTS, GND
 RS485: Data+ (A), Data- (B)
 Interface: DB9 female
System
 LED indicators: RUN, PPP, USR, 3 x RSSI
 Built-in RTC, Watchdog, Timer
 Expansion: 1 x USB 2.0 host up to 480 Mbps
Software
 Network protocols: PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, DMZ, RIP v1/v2, OSPF, DDNS, VRRP, HTTP, HTTPs, DNS,
ARP, QoS, SNTP, Telnet, IP Passthrough, etc.
 VPN tunnel: IPSec/OpenVPN/PPTP/L2TP/GRE
 Firewall: SPI, anti-DoS, Filter, Access Control

Robustel GoRugged R3000 Lite Specifications

General

Model	GoRugged R3000 Lite
Category	Network Router
Cellular Network	4G LTE
Ethernet Ports	2 x 10/100 Mbps
Ingress Protection	IP30
Antenna Connectors	SMA
VPN Support	IPsec, OpenVPN, GRE
Power Supply	9 ~ 36 VDC
