Robustel GoRugged R3000 Lite - IP Routing Configuration

Robustel GoRugged R3000 Lite User Guide
RT_UG_R3000 Lite_v.1.4.1 15.11.2016 60 / 135
Confidential
3.18 Configuration > IP Routing
This section allows users to set the IP routing parameters.
Static Route @ IP Routing
Item
Description
Default
Static Route Table
Allow users to add, delete or modify static route rules manually.
Null
Interface
Select from “WAN”, “LAN_0”.
WAN
Destination
Enter the destination host’s IP address or destination network.
Null
Netmask
Enter the Netmask of the destination or destination network.
Null
Gateway
Enter the gateway’s IP address of this static route rule. Router will forward all
the data which fit for the destination and Netmask to this gateway.
Null
