rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Bulk: guarantees that the minimum global rate of router is 1% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
IP Address @ QoS IP
Control List
Enter IP address of the user (for example, PC) who you want to set it with QoS
Control. Router supports up to 20 users set with QoS IP Control. If want to
control one network segment, user can set “IP Address” as format “x.x.x.x/24”
or “x.x.x.x/255.255.255.0”. For example, if we to control network segment
“172.16. x.x”, we can set “172.16.0.0/16” or “172.16.0.0/255.255.0.0” in “IP
Address”.
Null
Priority @ QoS IP
Control List
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”.
Select the priority of the user (for example, PC) who you want to set it with QoS
Control.
Exempt: this is the highest priority which guarantees that the minimum global
rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Bulk: guarantees that the minimum global rate of router is 1% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Exempt
Note: If services are in the same priority level, router will automatically start Stochastic Fairness Queueing (SFQ)
strategy to make a fair bandwidth allocation.
