Robustel GoRugged R3000 Lite User Guide
RT_UG_R3000 Lite_v.1.4.1 15.11.2016 58 / 135
Confidential
Default Percent
Definition
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”. Users
(Services) with no other pre-priority set will use this default priority.
Exempt: this is the highest priority which guarantees that the minimum global
rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Bulk: guarantees that the minimum global rate of router is 1% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal
Default Priority
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”.
Normal
Service Name @ QoS
Service Control List
Set server name of the service that you want to set it with QoS Control. Router
supports up to 20 users set with QoS Service Control. Priority of QoS Service
Control is higher than that of both QoS IP control and QoS MAC control.
Null
Protocol @ QoS
Service Control List
Select from “TCP”, “UDP” and “TCP&UDP”.
TCP
Port @ Service
Control List
Enter the port number of the service that you want to set it with QoS Control.
Null
Priority @ QoS
Service Control List
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”.
Select the priority of the service that you want to set it with QoS Control.
Exempt: this is the highest priority which guarantees that the minimum global
rate of router is 50% of “Downlink Speed”, and the maximum rate can reach to
100% of “Downlink Speed”.
Premium: guarantees that the minimum global rate of router is 25% of
“Downlink Speed”, and the maximum rate can reach to 100% of “Downlink
Speed”.
Express: guarantees that the minimum global rate of router is 15% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Normal: guarantees that the minimum global rate of router is 10% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Bulk: guarantees that the minimum global rate of router is 1% of “Downlink
Speed”, and the maximum rate can reach to 100% of “Downlink Speed”.
Exempt
MAC Address @ QoS
MAC Control List
Enter MAC address of the user (for example, PC) who you want to set it with
QoS Control. Router supports up to 20 users set with QoS MAC Control. Priority
of QoS MAC Control is higher than that of QoS IP control.
Null
Priority @ QoS MAC
Control List
Select from “Exempt”, “Premium”, “Express”, “Normal” and “Bulk”.
Select the priority of the user (for example, PC) who you want to set it with QoS
Control.
Exempt: this is the highest priority which guarantees that the minimum global
Exempt
