stands for “Router’s extern IP”.
ID: Uses custom string as the ID in IKE negotiation.
FQDN: Uses an FQDN type as the ID in IKE negotiation. If this option is selected,
type a name without any at sign (@) for the local security gateway, e.g.,
test.robustel.com.
User FQDN: Uses a user FQDN type as the ID in IKE negotiation. If this option is
selected, type a name string with a sign “@” for the local security gateway, e.g.,
test@robustel.com.
Select from “DES”, “3DES” and “AES128” to be used in IKE negotiation.
DES: Uses the DES algorithm in CBC mode and 56-bit key.
3DES: Uses the 3DES algorithm in CBC mode and 168-bit key.
AES128: Uses the AES algorithm in CBC mode and 128-bit key.
Select from “MD5” and “SHA1”to be used in IKE negotiation.
MD5: Uses HMAC-SHA1.
SHA1: Uses HMAC-MD5.
Select from “MODP768_1”, “MODP1024_2” and “MODP1536_5”to be used in
key negotiation phase 1.
MODP768_1: Uses the 768-bit Diffie-Hellman group.
MODP1024_2: Uses the 1024-bit Diffie-Hellman group.
MODP1536_5: Uses the 1536-bit Diffie-Hellman group.
Select from “DES_MD5_96”, “DES_SHA1_96”, “3DES_MD5_96”, “3DES_
SHA1_96”, “AES128_MD5_96”, “AES128_ SHA1_96” when you select “ESP” in
“Protocol”;
Select from “AH_MD5_96” and “AH_ SHA1_96” when you select “AH” in
“Protocol”;
Note: Higher security means more complex implementation and lower speed.
DES is enough to meet general requirements. Use 3DES when high
confidentiality and security are required.
Select from “PFS_NULL”, “MODP768_1”, “MODP1024_2” and “MODP1536_5”.
PFS_NULL: Disable PFS Group
MODP768_1: Uses the 768-bit Diffie-Hellman group.
MODP1024_2: Uses the 1024-bit Diffie-Hellman group.
MODP1536_5: Uses the 1536-bit Diffie-Hellman group.
The hold time of Nhrp protocol
