Operator’s Manual · Version 3.1 E-55
Cedex Bio System 14 ISE maintenance
ISE maintenance actions
Removing the tubing 7 Open the cover of the peristaltic pump.
8 Push the pump towards the back of the instrument.
9 Disengage the tube connector plate.
10 Remove the ISE pump tubing set.
Installing the tubing Install the tubing in the reverse order of removing it.
11 Pull the new tubing set over the pump head, with the connector plate facing the
electrode block.
A Cover of peristaltic pump
Figure E-10
A Connector plate
Figure E-11
A ISE pump tubing set
Figure E-12
A
A
A
