222 Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022
Chapter 8
Ethernet Issues
Tab l e 54 provides tips for isolating Ethernet anomalies.
Performance Is Slow
If the response time of the application is slow, for example screen changes or
text display changes, check for the following issues:
• Application screens contain too many elements.
• If the controller is programmed for feedback, it can cause delays.
• Slow network performance or noise can result in retries.
Resistance to Chemicals
The outer surfaces of the terminal including the bezel, touch screen overlay,
and panel gasket seal are tested for chemical resistance. Some of the chemicals
can cause discoloration, but they do not interfere with the operation of the
terminal.
TIP Extend the life of the backlight by reducing the display brightness, by using
the screen saver with reduced brightness, or operating at lower
temperatures.
Table 54 - Ethernet Connection Issues
Check for These Issues What to Do
Status of invalid Ethernet connection • Green indicator is on when a link is established.
• Yellow indicator blinks when activity is detected.
• Verify network connections.
Poor cable connections Check the Ethernet cabling for the following:
• Make sure that cables are fully connected.
• Check for cable crimping.
• Check the Ethernet switch connections.
• Check the Uplink ports.
Invalid IP address of terminal Go to Set the Ethernet Address of the Terminal
on page 88.
If DHCP is enabled, the terminal automatically acquires a valid IP
address from the network after startup. The TCP/IP protocol
automatically assigns 169.254.xxx.xxx when it fails to acquire an
IP address from the network. In general, an IP address that begins
with 169 does not support a network connection.
Conflicting IP addresses If DHCP is not enabled and a static IP address is specified, make
sure that the IP address does not conflict with the address of
another device on the network.
TIP For more information on chemical resistance of the product, go to
https://rockwellautomation.custhelp.com
and search the Knowledgebase
for keywords ‘Chemical Resistance PanelView Plus’.
IMPORTANT Do not operate the terminal in direct sunlight. Direct exposure to ultraviolet
light can discolor the touch screen.
