76 Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022
Chapter 3
Terminal Settings
The terminal has settings that you can adjust that are not specific to the
application.
1. Press Terminal Settings from the FactoryTalk View ME Station dialog
box.
2. Select an option by using the up and down cursor.
• On touch screen terminals, touch the up or down cursor.
• On keypad terminals, press the corresponding key on the keypad.
3. Press Enter to access the selected function.
Table 20 - Terminal Settings
Select This Option: If You Want to:
Alarms Close the alarm display on the terminal when an operator acknowledges the newest alarm. By default, the alarm display is closed.
Diagnostics Setup Forward diagnostic messages from a remote log destination to a computer that runs diagnostics.
Display Adjust the brightness of the display, configure the screen saver, and enable/disable the touch screen cursor.
Desktop Access Setup Allow or restrict access to the desktop. Set or reset the desktop password (Series A terminals exit to the desktop. Series B terminals
(Series C for Stainless Steel terminals) exit to the Control Panel).
File Management Copy application files and font files to the terminal, an SD card, or a USB drive. You can also delete application files or log files.
Font Linking Link a font file to a base font loaded on the terminal.
Input Devices Configure settings for the keypad, attached keyboard, mouse, or touch screen, including touch screen calibration. You can also choose
between a popup character input or popup keyboard for string input.
File Integrity Check Check the integrity of the .mer application file and runtime files by logging details to a file integrity check log. You can view and clear
this log at any time.
Networks and Communications Configure Ethernet and other communication settings for an application. KEPServer Driver Configuration is a new option available on
both Series A and Series B terminals (Series C for Stainless Steel terminals).
Print Setup Configure settings to print displays, alarm messages, or diagnostics messages generated by the application.
Startup Options Specify whether the terminal launches the desktop, an application, or FactoryTalk View ME Station Configuration mode on startup.
System Event Log Display system events that are logged by the terminal, and clear events from the log.
System Information Display power, temperature, battery, and memory details for the terminal. You can also view the firmware revision for FactoryTalk View
ME Station, and other software loaded on the terminal. Technical support information.
Time/Date/Regional Settings Set the date, time, language, and numeric format used by terminal and applications.
Certificates Management Import and view certificates on the terminal.
