30 Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022
Chapter 2
Mounting Clearances
Plan for adequate space around the terminal, inside the enclosure, for
ventilation and cabling. Consider heat that is produced by other devices in the
enclosure.
The ambient temperature around the terminal must be 0…55 °C (32…131 °F),
except for the 19-in. Series A terminal, which has an ambient temperature
requirement of 0…50 °C (32…122 °F). The ambient temperature for the 19-in.
Series B terminal (Series C for the Stainless Steel terminals) is 0…55 °C
(32…131 °F).
Panel Guidelines
The terminals are panel-mount devices that mount in the door or wall of a
NEMA rated, UL Type rated, or IP rated enclosure:
• Panels must have a thickness of 1.5…4.8 mm (0.060…0.188 in.).
• The material strength and stiffness of the panel must be sufficient to
hold the terminal and maintain an appropriate seal against water and
dust.
• The panel surface must be flat and free of imperfections to maintain an
adequate seal, and NEMA and UL Type ratings.
Panel Cutout Dimensions
Use the template that is shipped with your terminal to mark the cutout
dimensions.
Table 13 - Minimum Required Clearances
Product Area Minimum Clearance
Top 51 mm (2 in.)
Bottom 102 mm (4 in.)
Sides 25 mm (1 in.) on side without an SD card
102 mm (4 in.) on side with an SD card
Back 0 mm (0 in.)
(1)
(1) When mounting a stainless steel terminal on a panel thicker than 3.66 mm (0.144 in.), the minimum clearance is from the
mounting clip, not the back of the terminal.
Table 14 - Panel Cutout Dimensions - PanelView Plus 7 Performance Terminals
Terminal Size Input Type Height, mm (in.) Width, mm (in.)
6.5-in.
Keypad and touch 142 (5.59) 237 (9.33)
Touch 142 (5.59) 184 (7.24)
9-in. Touch 162 (6.38) 252 (9.92)
10.4-in.
Keypad and touch 224 (8.82) 335 (13.19)
Touch 224 (8.82) 269 (10.59)
12.1-in. Touch 218 (8.58) 312 (12.28)
15-in.
Keypad and touch 290 (11.42) 418 (16.46)
Touch 290 (11.42) 353 (13.90)
19-in. Touch 383 (15.08) 457 (17.99)
