Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 193
Chapter 7
Update Firmware
Terminal Firmware
Firmware components are packaged as execute-in-place (XIP) regions in a
System Code (SC) .img file. When the SC .img file is copied to the Virtual File
System (VFS) on the terminal, the terminal XIP regions are updated and the
terminal restarts automatically. These firmware components are affected
during an update:
• FactoryTalk® View Machine Edition Station software
• Communication protocols and drivers including Kepware drivers
•Windows fonts
•Windows CE components
• FactoryTalk components
• User extensions
Note: The description of XIP and VFS is only applicable to PanelView Plus 7
Performance Series A terminals.
A firmware update does not affect these terminal components or settings:
•Windows registry
• File system including the FactoryTalk View Machine Edition
application that is loaded
(1)
in the terminal
• Network parameters including the network device name, DHCP-
enabled and static
(2)
IP addressing, speed, and duplex setting
• Display settings and screen saver configuration
• Touch screen calibration
Topic Page
Terminal Firmware 193
Download Firmware Files (Series A Terminals Only) 194
Firmware Upgrade Wizard (Series A Terminals Only) 195
Upgrade Terminal Firmware from a Storage Device (Series A
Terminals Only)
195
Update Terminal Firmware Over the Network (Series A Terminals
Only)
199
Update System Firmware (Series B Terminals Only) 203
Update DLR Network Switch Firmware (Series B Terminals Only) 213
(1) In some cases, the FactoryTalk View ME application can be missing after a firmware update.
(2) In some cases, static IP addresses have been changed to DHCP-enabled IP address after a firmware update.
