Rockwell Automation Publication 2080-QS004C-EN-E - October 2023 61
Chapter 12
Quick Tips
Table 1 provides a list of keyboard shortcuts that you can use in Connected Components Workbench software.
Table 1 - Keyboard Shortcuts in Connected Components Workbench Software
Shortcut Description
Working with Rungs
Ctrl + 0
Inserts a rung after a selected rung
(1)
(1) When no rung is selected, a rung is added at the end of the rung list.
Ctrl + Alt + 0
Inserts a rung before a selected rung
(1)
Working with Branches
Ctrl + 1 Inserts a branch after a selected element
Ctrl + Alt + 1 Inserts a branch before a selected element
Ctrl + 7 Inserts a branch under the selected element
Working with Instructions
Ctrl + 2 Inserts an Instruction Block after a selected element
Ctrl + Alt + 2 Inserts an Instruction Block before a selected element
Working with Contacts
Ctrl + 3
Inserts a contact after a selected element
(2)
(2) When a branch is selected, an element is inserted at the end of the branch.
Ctrl + Alt + 3
Inserts a contact before a selected element
(2)
Working with Coils
Ctrl + 4
Inserts a coil after a selected element
(2)
Ctrl + Alt + 4
Inserts a coil before a selected element
(2)
Spacebar For coils or contacts, toggles between the available types
F1 Invokes context-sensitive Help
