Chapter 2 Replacement Considerations
Internal shunt
Co
ntinuous power
Peak power
———50 W
4.5 W
50 W
10 kW
180 W
18 kW
External shunt
Resistance
Continuous power
Peak power
———
30 ohms (-0/+5%)
2.4 kW
6 kW
16.5 ohms (-0/+5%)
4 kW
10 kW
9 ohms (-0/+5%)
8 kW
19 kW
Energy absorption capability
115V AC input
230V AC input
93 J
38 J
125 J
51 J
251 J
139 J
381 J
211 J
669 J
370 J
Continuous power output
115V AC input
230V AC input
0.25 kW
0.5 kW
0.5 kW
1.0 kW
1.0 kW
2.0 kW
1.5 kW
3 kW
—
7.5 kW
—
15 kW
(1) Specification is for nominal voltage. The absolute limits are ± 10%, or 88…265V rms.
(2) The 2098-DSD-005x-xx, 2098-DSD-010x-xx (200V - class) drives are limited to:
Series A or B - one contactor cycle every two minutes.
Series C - one contactor cycle every 10 s for up to two minutes, not to exceed 12 cycles in five minutes.
(3) Power initialization requires a short period of inrush current. Dual element time delay (slow blow) fuses are recommended.
(4) Inrush current limiting circuitry is enabled within 3 s after removal of AC line power.
Table 13 - Ultra3000 (200V-class) Servo Drive Power Specifications (Continued)
Attribute 2098-DSD-005 2098-DSD-010 2098-DSD-020 2098-DSD-030 2098-DSD-075 2098-DSD-150
