26 Rockwell Automation Publication 2198-RM003B-EN-P - November 2020
Chapter 2 Replacement Considerations
I/O Availability and
Specifications
All Ultra3000 drives and Kinetix 5100 drives have a comprehensive set of
digital I/O and analog I/O. Use this section to verify if the I/O functionality is
comparable.
Digital Inputs
Table 19 compares the digital inputs of the Ultra3000 drives and the Kinetix
5100 drives.
Kinetix 5100 drives have eight inputs with configurable functions and two
high-speed inputs. The standard digital inputs on Kinetix 5100 drives have the
same physical characteristics. Table 20
and Table 21 compare the digital inputs
physical characteristics between Ultra3000 and Kinetix 5100 drives.
Table 19 - Digital Inputs Comparison
Features Ultra3000 (Non-Sercos) Drives Kinetix 5100 Drives
Inputs Eight inputs
Ten total (eight standard inputs, two
optional high-speed inputs)
DC common terminations 1 1
Number of Pre-selectable indexes
(using binary weighted digital inputs)
64 99
Multiple input assignment Yes Yes (via software programming)
De-bounce for inputs Yes, can be assigned to any input Yes
Registration Input Yes, can be assigned to any input
Yes, can be assigned to two high-
speed inputs (Input 9 and Input 10)
Overtravels contact type N.C. only Can be N.O. or N.C.
Default assignment for digital inputs/
outputs
None Yes
Table 20 - Digital Inputs Characteristics Comparison
Specification Ultra3000 Drives Kinetix 5100 Drives
Digital Input response
(delay)
100 μs
Standard inputs: 1 ms
High speed inputs: 3us
Digital Input scan time 1 ms
Standard inputs: 500us max
High speed inputs: 1us
Table 21 - Digital Inputs Voltage and Current Comparison (IEC61131-2 Type 1 compliant for
Kinetix 5100 Drive)
Parameter Description
Ultra3000 Drive Kinetix 5100 Drive
Min Max Min Max
ON state voltage
Voltage applied to the input, with respect
IOCOM, to guarantee an ON state
10.8V 26.4V 15V 26.4V
ON state current Current flow to guarantee an ON State 3.0 mA 12.0 mA 2.0 mA 6.0 mA
OFF state voltage
Voltage applied to the input, with respect
IOCOM, to guarantee an OFF state
-1.0V 2.0V -1.0V 5.0V
