Rockwell Automation Publication 2198-RM003B-EN-P - November 2020 25
Chapter 2 Replacement Considerations
Table 18 - Kinetix 5100 Power Specifications (480V nom three-phase, continued)
Attribute 2198-E4030-ERS 2198-E4055-ERS 2198-E4075-ERS 2198-E4150-ERS
AC input voltage 342…528V rms, three-phase (380/480V nom)
AC input frequency 47…63 Hz
Mains AC input current
(1)
Nom (rms) 380V input (three-phase)
Max inrush (0-pk) 380V input
Nom (rms) 480V input (three-phase)
Max inrush (0-pk) 480V input
9.96 A
9.43 A
7.91 A
11.91 A
16.825 A
9.43 A
13.35 A
11.91 A
23.664 A
9.43 A
18.78 A
11.91 A
36.855 A
28.28 A
29.25 A
35.73 A
Control power input voltage
21.6…26.4V DC,
24V DC nom
Control power input current @ 24V DC
(2)
Control power in-rush current @ 24V DC
1.77 A
DC
4.97 A
DC
2.03 A
DC
3.24 A
DC
4.43 A
DC
3.40 A
DC
Continuous output current (rms) 13.95 A 24.8 A 31.0 A 41.26 A
Continuous output current (0-pk) 19.73 A 35.07 A 43.84 A 58.35 A
Peak output current (rms)
(3)
26.08 A 37.65 A 53.32 A 70.14 A
Peak output current (0-pk) 36.88 A 53.24 A 75.39 A 99.18 A
Line loss ride through 20 ms
Continuous output power 3.0 kW 5.5 kW 7.5 kW 15.0 kW
Internal shunt on
760V
Internal shunt off
Internal shunt resistor – – – –
Internal shunt power – – – –
Bus undervoltage 282V
Bus overvoltage 820V
Bus capacitance 560 µF 1120 µF 1640 µF 2500 µF
Capacitive energy absorption 38.2 J 76.3 J 111.7 J 170.3 J
Short-circuit current rating 5,000 A (rms) symmetrical
(1) Kinetix 5100 drive modules are limited to 1 AC mains power cycling per minute.
(2) Kinetix 5100 drive modules are limited to 1 control power cycling every 20 seconds.
(3) Peak RMS current allowed for up to 1.8 seconds.
