Chapter 2 Replacement Considerations
Table 17 - Kinetix 5100 Power Specifications (480V nom three-phase)
Attribute 2198-E4004-ERS 2198-E4007-ERS 2198-E4015-ERS 2198-E4020-ERS
AC input voltage 342…528V rms, three-phase (480V nom)
AC input frequency 47…63 Hz
Mains AC input current
(1)
Nom (rms) 380V input (three-phase)
Max inrush (0-pk) 380V input
Nom (rms) 480V input (three-phase)
Max inrush (0-pk) 480V input
1.49 A
5.66 A
1.34 A
7.15 A
2.31 A
5.66 A
2.08 A
7.15 A
5.009 A
5.66 A
4.38 A
7.15 A
6.29 A
9.43 A
4.94 A
11.91 A
Control power input voltage
21.6…26.4V DC
24V DC nom
Control power input current @ 24V DC
(2)
Control power in-rush current @ 24V DC
1.27 A
DC
4.14 A
DC
1.40 A
DC
4.97 A
DC
Continuous output current (rms) 1.60 A 3.19 A 6.05 A 7.42 A
Continuous output current (0-pk) 2.26 A 4.51 A 8.56A 10.49 A
Peak output current (rms)
(3)
5.40 A 8.0 A 15.11 A 20.78 A
Peak output current (0-pk) 7.63 A 11.31 A 21.36 A 29.38 A
Line loss ride through 20 ms
Continuous output power 0.40 kW 0.75 kW 1.50 kW 2.0 kW
Internal shunt on
760V
Internal shunt off
Internal shunt resistor 80 Ω –
Internal shunt power 10 W –
Bus undervoltage 282V
Bus overvoltage 820V
Bus capacitance 165 µF 235 µF 470 µF
Capacitive energy absorption 11.2 J 16.0 J 32.0 J
Short-circuit current rating 5,000 A (rms) symmetrical
(1) Kinetix 5100 drive modules are limited to 1 AC mains power cycling per minute.
(2) Kinetix 5100 drive modules are limited to 1 control power cycling every 20 seconds.
(3) Peak RMS current allowed for up to 1.8 seconds.
