Rockwell Automation Publication 2198-RM003B-EN-P - November 2020 23
Chapter 2 Replacement Considerations
Table 16 - Kinetix 5100 Drive Input Power Specifications (three-phase)
Attribute 2198-E2030-ERS 2198-E2055-ERS 2198-E2075-ERS 2198-E2150-ERS
AC input voltage 170…253V rms, 3 PH (230V nom)
AC input frequency 47…63 Hz
Main AC input current
(1)
rms (Nom) 230V input (3 PH)
max inrush (0-pk) 230V input
14.65 A
4.42 A
27.32 A
9.55 A
37.90 A
28.68 A
70.45 A
32.0 A
Control power input voltage 170…253V rms, 200…230V AC nom, 1 PH, with 200…230V AC input power
Control power input current
rms (Nom) 230V input
max inrush (0-pk)
0.35 A
36.40 A
0.46 A
32.80 A
0.48 A
40.0 A
0.92 A
37.0 A
Continuous output current (rms) 17.9 A 41.3 A 49.0 A 78.0 A
Continuous output current (0-pk) 25.3 A 58.4 A 69.3 A 110.3 A
Peak output current (rms)
(2)
55.95 A 91.4 A 127.5 A 162.0 A
Peak output current (0-pk) 79.1 A 129.2 A 180.3 A 229.1 A
Continuous power output
@ 230V nom 3.0 kW 5.5 kW 7.5 kW 15.0 kW
Internal shunt on
370V @230V AC input
Internal shunt off
Internal shunt resistor 20 Ω – – –
Internal shunt power 20 W – – –
Undervoltage threshold 150V @230V AC input
Overvoltage 410V @230V AC input
Bus capacitance 2160 µF 4100 µF 7000 µF 13,500 µF
Capacitive energy absorption 24.95 J 47.36 J 69.30 J 155.93 J
Short-circuit current rating 5000 A (rms) symmetrical
(1) Kinetix 5100 drive modules are limited to one AC mains power cycling per minute.
(2) Peak RMS current that is allowed for up to 1.8 seconds.
