Rockwell Automation Allen-Bradley Ultra3000 Migration Guide

Rockwell Automation Publication 2198-RM003B-EN-P - November 2020 39
Chapter 2 Replacement Considerations
For the Kinetix 5100 drive, the AC line filters are mounted directly beside the
drive (side) with flying lead connections.
Table 40 - Ultra3000 Drives AC Line Filter Selection
Drive Family Drive Cat. No. AC Line Filter Cat. No. Motor Cables > 30 m (98.4 ft)
Ultra3000 drive
2098-xxx-005 2090-UXLF-106 2090-UXLF-110
2098-xxx-010 2090-UXLF-110 2090-UXLF-110
2098-xxx-020 2090-UXLF-123 2090-UXLF-123
2098-xxx-030 2090-UXLF-136 2090-UXLF-132
2098-xxx-075 2090-UXLF-336 2090-UXLF-HV330
2098-xxx-150 2090-UXLF-350 2090-UXLF-HV350
2098-DSD-HV030,
2098-DSD-HV050,
2098-DSD-HV100,
2098-DSD-HV150
2090-UXLF-HV323 2090-UXLF-HV323
2098-DSD-HV220 2090-UXLF-HV330 2090-UXLF-HV330
Table 41 - AC Line Filter Specifications
AC Line Filter
Cat. No.
Voltage Phase
Specifications
(1) (2)
(1) For all filters, 90% relative humidity.
(2) For all filters, 10…200 Hz @ 1.8 g vibration.
Current A @
50 °C (122 °F)
Power
Loss W
Leakage
Current
mA
Weight
approx
kg (lb)
Operating
Temperature
2090-UXLF-106
250V AC
50/60 Hz
1 PH
6 3.5 2.26 0.3 (0.66)
-25…+85 °C
(-13…+185 °F)
2090-UXLF-110 10 2.7 45 0.95 (2.0)
2090-UXLF-123 23 10 90
1.6 (3.5)
2090-UXLF-132 32 20 90
2090-UXLF-136 36 – 200 1.75 (3.9)
2090-XXLF-TC116 16 – 87 0.80 (1.7)
-25…+100 °C
(-13…+212 °F)
2090-UXLF-336
3 PH
36 – 138
2.7 (5.9)
-25…+85 °C
(-13…+185 °F)
2090-UXLF-350 50 25 138
Table 42 - Kinetix 5100 Drives AC Line Filter Catalog Numbers
Kinetix 5100 Drive
Cat. No.
AC Line Filter Cat. No.
(single-phase operation)
AC Line Filter Cat. No.
(three-phase operation)
2198-E1004-ERS 2198-DB111-F
2198-DB310-F
2198-E1007-ERS
2198-DB127-F2198-E1015-ERS
2198-DB324-F
2198-E1020-ERS
2198-E2030-ERS
(1)
(1) 2198-E2xxx-ERS and 2198-E4xxx-ERS servo drives do not support single-phase operation.
—
2198-E2055-ERS
(1)
— 2198-DB335-F
2198-E2075-ERS
(1)
—2198-DB356-F
2198-E2150-ERS
(1)
— 2198-DBR90-F
2198-E4004-ERS –
2198-DB418-F
2198-E4007-ERS –
2198-E4015-ERS –
2198-E4020-ERS –
2198-E4030-ERS –
2198-E4055-ERS –
2198-B433-F
2198-E4075-ERS –
2198-E4150-ERS – 2198-DBR40
