Rockwell Automation Allen-Bradley Ultra3000 Migration Guide

Rockwell Automation Publication 2198-RM003B-EN-P - November 2020 45
Chapter 3 Connectors and Indicators
Figure 14 - 2098-DSD-HV030, 2098-DSD-HV050, 2098-DSD-HV100, 2098-DSD-HV150, and
2098-DSD-HV220 Ultra3000 (400V-class) Drives
Item Description Item Description
1 AC input power connections 8 CN2 15-pin motor feedback connector
2
DC bus connections for active shunt resistor
kit
9 CN1 44-pin user I/O connector
3 Motor power connections 10 Module status indicator
4 Passive shunt resistor connections 11 Network status indicator
5 Seven-segment fault status indicator 12 Node address switches
6 Logic power 13 Data rate switch
7 CN3 9-pin serial port connector 14 DeviceNet interface connector
W
V
U
+
-
L3
L2
L1
L1
AUX
L2
AUX
Motor
DC Bus
230-480 VAC
50/60 Hz
Internal
External Shunt
1
2
3
TB2
DANGERDANGER
Hazardous voltage
exists after power down.
TB1
Can_H
V+
500kB
250kB
125kB
AUTO
PGM
V-
Can_L
Shield
(00-63, PGM)
DeviceNet
14
1
2
3
9
8
7
6
5
4
12
11
10
13
2098-DSD-HVxxx and 2098-DSD-HVxxxX
Ultra3000 and Ultra3000 Indexing Drives
2098-DSD-HVxxx-DN and
2098-DSD-HVxxxX-DN
Ultra3000 DeviceNet and
DeviceNet Indexing Drives
