Adapter Parameters B-7
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
[Flt Cfg DL 01]
[Flt Cfg DL 02]
[Flt Cfg DL 03]
[Flt Cfg DL 04]
[Flt Cfg DL 05]
[Flt Cfg DL 06]
[Flt Cfg DL 07]
[Flt Cfg DL 08]
[Flt Cfg DL 09]
[Flt Cfg DL 10]
[Flt Cfg DL 11]
[Flt Cfg DL 12]
[Flt Cfg DL 13]
[Flt Cfg DL 14]
[Flt Cfg DL 15]
[Flt Cfg DL 16]
Sets the data that is sent to the Datalink in the
drive if any of the following is true:
• Parameter 54 - [Comm Flt Action] is set to
“4” (Send Flt Cfg) and I/O communications
are disrupted.
• Parameter 55 - [Idle Flt Action] is set to “4”
(Send Flt Cfg) and the controller is idle.
• Parameter 56 - [Peer Flt Action] is set to
“4” (Send Flt Cfg) and Peer I/O
communications are disrupted.
• Parameter 57 - [Msg Flt Action] is set to
“4” (Send Flt Cfg) and explicit messaging for
drive control is disrupted.
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 4294967295
Type: Read/Write
Reset Required: No
76 [DLs Fr Peer Cfg]
Sets the number of network-to-drive Datalinks
(parameters) that are used for peer I/O. The
Datalinks being used are allocated from the
end of the list. For example, if this parameter's
value is set to “3,” Datalinks 14-16 are
allocated for the 3 selected Datalinks. The
Datalinks allocated for peer I/O cannot overlap
with other assigned DL From Net 01-16
parameters.
Default: 0
Minimum: 0
Maximum: 16
Type: Read/Write
Reset Required: Yes
77 [DLs Fr Peer Act]
Displays the value of Parameter 76 - [DLs Fr
Peer Cfg] at the time the drive was reset. This
is the number of actual peer-to-drive Datalinks
that the drive is expecting.
Default: 0
Minimum: 0
Maximum: 16
Type: Read Only
78 [Logic Src Cfg]
Controls which of the peer-to-drive Datalinks
contain the Logic Command for the drive.
Default: 0
Minimum: 0
Maximum: 16
Type: Read/Write
Reset Required: No
79 [Ref Src Cfg]
Controls which of the peer-to-drive Datalinks
contain the Reference for the drive.
Default: 0
Minimum: 0
Maximum: 16
Type: Read/Write
Reset Required: No
Parameter
No. Name and Description Details
