B-8 Adapter Parameters
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
80 [Fr Peer Timeout]
Sets the timeout for a Peer I/O connection. If
the time is reached without the adapter
receiving (consuming) a message, the adapter
will respond with the action specified in
Parameter 56 - [Peer Flt Action].
In an adapter receiving (consuming) Peer I/O,
the value of this parameter must be greater
than the product of the value of Parameter 89
- [To Peer Period] in the adapter transmitting
(producing) Peer I/O multiplied by the value of
Parameter 90 - [To Peer Skip] in the adapter
transmitting (producing) Peer I/O.
Default: 10.00 Seconds
Minimum: 0.01 Seconds
Maximum: 10.00 Seconds
Type: Read/Write
Reset Required: No
81
82
83
84
[Fr Peer Addr 1]
[Fr Peer Addr 2]
[Fr Peer Addr 3]
[Fr Peer Addr 4]
Sets the bytes in the IP address that specifies
the device from which the adapter receives
(consumes) Peer I/O data.
Important: The Peer Inp Addr must be on the
same subnet as the embedded EtherNet/IP
adapter. Refer to IP Addresses
on page G-4
for more information.
Changes to these parameters are ignored
when Parameter 85 - [Fr Peer Enable] is “1”
(On).
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 255
Type: Read/Write
Reset Required: No
85 [Fr Peer Enable]
Controls whether Peer I/O input is operating. A
value of “0” (Off) turns off Peer I/O input. A
value of “1” (Cmd/Ref) overrides the settings
in Parameters 76 - [DLs Fr Peer Cfg], 78 -
[Logic Src Cfg], and 79 - [Ref Src Cfg] and
automatically uses peer Datalink 01 as the
drive's present Logic Command and peer
Datalink 02 as the drive's Reference. A value
of “2” (Custom) enables peer I/O input using
the Datalink count and settings provided by
the user.
Default: 0 = Off
Values: 0 = Off
1 = Cmd/Ref
2 = Custom
Type: Read/Write
Reset Required: No
86 [Fr Peer Status]
Displays the status of the consumed Peer I/O
input connection.
Default: 0 = Off
Values: 0 = Off
1 = Waiting
2 = Running
3 = Faulted
Type: Read Only
Parameter
No. Name and Description Details
255 . 255 . 255 . 255
[Peer Inp Addr 1]
[Peer Inp Addr 2]
[Peer Inp Addr 3]
[Peer Inp Addr 4]
