118 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 6 Frame 7 Components

14. For the motor side inverter module, remove the six M8 x 30 mm torx

screws that secure the AC output flexible bus bars to the AC output

terminals on the power module, and remove the flexible bus bars.

M8 x 30 mm

T40

19.8 N•m (175 lb•in)
