170 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 7 Control Bay and Control Pod Components

16. Loosen the four M4 x 8 mm torx screws that secure the pod chassis to the

back panel.

17. Slide the pod up, so that the keyholes on the pod clear the mounting

screws, and remove the control pod.

M4 x 8 mm

T20 or F - 5 mm (0.19 in.)

2.6 N•m (23 lb•in)
