246 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 9 Power Bay Components

6. Disconnect the cable connector P13 from connector J13 on the power

layer interface circuit board.

CTL

J13

PDI

Default Chapter3
