Rockwell Automation Publication 750-TG100B-EN-P - June 2019 247

Power Bay Components Chapter 9

7. Disconnect these cable connectors from the power interface circuit board:

•P3 from J3

•P4 from J4

•P7 from J7

•P8 from J8

•P9 from J9

• P10 from J10

• P11 from J11

• P12 from J12

8. Remove all cables from the cable mounts on the front of the circuit board

tray.

J12

J10

J11
