Setup of Media
2
Basic Operation
34
4. Perform the position correction of the feed direction (reduce horizontal stripes).

Press to select [SET].
Press
to conrm your entry.
The test pattern of feed correction is output.

When the screen shown on the left is displayed, press
.

Use and to set the correction value.
Press
to conrm your entry.

To conrm again/adjust again
Press
to select [YES].
Press
to conrm your entry.
The test pattern of feed correction is output again. Go back to step

and perform the setting again.
To go to the next step after correction is completed
Press
to select [DONE].
Press
to conrm your entry.
For the individual setting method and the description of this setting item, refer to the following section.

P. 92, "Alleviating Horizontal Bands (Feed Correction Function)"
Feed direction means the feed direction of the media. Perform the correction adjusting to the media
in advance because horizontal strips are more likely to occur during printing when the movement
distance of the media changes subtly depending on the media’s type or thickness.
CALIBRATION
[SET] NEXT
INPUT
ADJ. VALUES
CALIBRATION
0.00% -0.40%
To decide a correction value
Select the value to make the upper/lower rectangular gap and overlap smallest.
REDO ADJ.?
[YES] DONE
Gap present Overlap
= Current
correction value
Smallest gap and overlap
Current cor-
rection value
Value to
be set
