RootWave Pro User Guide

15. Disconnect the system

Disconnect the Treatment Lance cable,

Treatment Earth cable, and the

generator cable.

Remove the Safety Earth from the

ground.

Disconnect the Treatment Return and

remove from ground as per step 13.

Notice

• Lubricants can reduce electrical conductivity. Keep

threads on Treatment Return Body and Blades clean

and dry and don’t use grease or other lubricants.

Store parts disassembled - don’t reassemble them

until installation.
