Rosemount 2130 - Vessel Installation; Cable Gland Orientation; Vessel Insulation

Reference Manual
00809-0100-4130, Rev AA
May 2009
2-3
Rosemount 2130
Vessel Installation
CABLE GLAND
ORIENTATION
VESSEL INSULATION
Ensure that any vessel insulation is a minimum of 2.1 in. (55 mm) away from
the electronics housing, as illustrated below.
2130/FIG8.EPS
> 3.35 in. (85 mm)
2130_MIN_NOZZLE_D.EPS
2130/FIG10.EPS
OK
2130_LAGGING.EPS
2.1 in.
(55 mm)
2.1 in.
(55 mm)
