Rosemount 2130 - Handling the 2130; Device Identification

Reference Manual
00809-0100-4130, Rev AA
May 2009
1-7
Rosemount 2130
HANDLING THE 2130
DEVICE IDENTIFICATION See Appendix B: Product Certifications for specific product approvals.
Figure 1-3.
Do not hold the 2130 by the forks.
Figure 1-4.
Do not alter the forks in any way.
2130/FIG1.JPG
2130/FIG2.JPG
2130 Vibrating Fork Level Switch
www.rosemount.com
DIR E C T LOAD S WITCHING
99500200
www .rosemount.com
MAGNETIC
TEST
POINT
20 - 264V ac
50 - 60Hz
20 - 60Vdc
Output Rating:
Load 20 - 500mA
~
Supply
2130##############
2130/2130_24AA.EPS
