SPECIFICATIONS
Physical Product
• Rosemount 2130 Extreme Temperature Vibrating Fork Liquid Level Switch
Measuring Principle
• Vibrating Fork
Applications
• Most liquids including coating liquids, aerated liquids, and slurries
Mechanical Housing/Enclosure
Connections
• See “Process Connection” on page A-1
Extended Lengths
• The maximum extended length is 118.1 in. (3000 mm), except for the
hand-polished version that is limited to 39.4 in. (1000 mm).
Table A-1.
Minimum Extended Length
Housing Code X Y S T
Housing
Material
Al alloy ASTM B26
356-T6 or LM25 TF
316C12 Stainless Steel
Housing Paint
Polyurethane
Powder Coat
Not Applicable
LED Window
None None
Conduit Entry
M20
3
/4-in. NPT M20
3
/4-in. NPT
Ingress
Protection
IP66/67 to EN60529,
Type 4X
IP66/67 to EN60529,
Type 4X
Process Connection Minimum Extended Length
3
/4–in Threaded 3.8 in. (95 mm)
1–in Threaded 3.7 in. (94 mm)
Flanged 3.5 in. (89 mm)
Tri-Clamp 4.1 in. (105 mm)
