Rosemount 2130 - 2130 Hygienic Fitting (Standard Length; 2130 Hygienic Fitting (Standard Length)

Reference Manual
00809-0100-4130, Rev AA
May 2009
A-9
Rosemount 2130
2130 Hygienic Fitting (Standard Length)
Note: Dimensions are in inches (millimeters)
Aluminum or
SST Housing
Cable Entry
M20x1.5 or
3
/4-in. NPT
1.14
(29)
1.73
(44)
14.2
(360)
2.8
(70)
1
/2-in. (38)
2-in. (51)
Tri-Clamp
1.575 (40)
A/F
Hexagon
1-in.
Thread
1.14
(29)
1.73
(44)
1.575 (40)
A/F
Hexagon
Cable Entry
M20x1.5 or
3
/4-in. NPT
Aluminum
or SST
Housing
2130_METAL_HOUSING_STD_HYGIENE.EPS
4.7 (120)
4.7 (120)
0.51 (13)
Switchpoint
(When Mounted
Horizontally)
0.51 (13)
Switchpoint
(When Mounted
Vertically)
0.51 (13)
Switch-
point
(Mounted
Vertically)
0.51 (13)
Switchpoint
(When Mounted
Horizontally)
2.8
(70)
13.8
(350)
Allow
1.2 (30)
For Lid
Allow
1.2 (30)
For Lid
2130_METAL_HOUSING_STD_HYGIENE_THREAD.EPS
